voc 催化燃燒設備工作原理，在化學反應過程中，利用催化劑降低燃燒溫度，加速有毒有害氣體氧化的方法，叫做催化燃燒法。由于催化劑的載體是由多孔材料制作的，具有較大的比表面積和合適的孔徑，當加熱到 3 。。一 45 。’ C 的有機氣體通過催化層時，氧和有機氣體被吸附在多孔材料表層的催化劑上，增加了氧和有機氣體接觸碰撞的機會，提高了活性，使有機氣體與氧產生劇烈的化學反應而生成 C02 和 H20 ，同時產生熱量，從而使得有機氣體變成無害氣體。
VOC catalytic combustion equipment working principle, in the chemical reaction process, the use of catalyst to reduce combustion temperature, accelerate the oxidation of toxic and harmful gases, is called catalytic combustion method. As the support of the catalyst is made of porous materials, it has a large specific surface area and suitable pore size.. 45. " When the organic gas of C passes through the catalytic layer, oxygen and organic gas are adsorbed on the catalyst on the surface of porous materials, which increases the chance of contact and collision between oxygen and organic gas, improves the activity, and makes the organic gas and oxygen produce violent chemical reaction to produce CO2 and H20, and at the same time generates heat, so that the organic gas becomes harmless gas.
與熱力燃燒法相比，催化燃燒所需的輔助燃料少能量消耗低，化劑的中毒、設備設施的體積小。但是，由于使用的催催化床層的換和清潔費用高等問題，影響了這種方法在工業生產過程中的推廣和應幣。
Compared with the thermal combustion method, catalytic combustion needs less auxiliary fuel, lower energy consumption, chemical poisoning and small volume of equipment and facilities. However, due to the high cost of catalyst bed replacement and cleaning, the popularization and application of this method in industrial production process are affected.

voc 催化燃燒設備是利用催化劑使有機廢氣在較低的起燃溫度下進行沒有火焰的燃燒以達到氧化分解的凈化裝置。催化燃燒設備的結構一般由阻火過濾器、換熱器、預熱室、熱電阻、催化床和防暴器組成，電控系統由 PLC 控制器、文本顯示器、變頻調速器、點火器、紫外線傳感器、熱電偶等電控設備，另外還有風機以及調節燃氣與空氣比例的零壓閥組成．
VOC catalytic combustion equipment is a kind of purification device which uses catalyst to make organic waste gas burn without flame at low ignition temperature to achieve oxidation and decomposition. The structure of catalytic combustion equipment is generally composed of fire-retardant filter, heat exchanger, preheating chamber, thermal resistance, catalytic bed and anti riot device. The electronic control system consists of PLC controller, text display, frequency converter, ignitor, ultraviolet sensor, thermocouple and other electrical control equipment. In addition, there are fans and zero pressure valves to adjust the proportion of gas and air
RCO 催化燃燒設備內設加熱室，啟動加熱裝置，進入內部循環，當熱氣源達到有機物的沸點時，有機物從活性炭內跑出來，進入催化室進行催化分解成 C02 和 H20 ，同時釋放出能量。利用釋放出的能量再進入吸附床脫附時，此時加熱裝置停止工作，有機廢氣在催化燃燒室內維持自燃，尾氣，循環進行，直至有機物從活性炭內部分離，至催化室分解。
The RCO catalytic combustion equipment is equipped with a heating chamber, which starts the heating device and enters the internal circulation. When the hot gas source reaches the boiling point of the organic matter, the organic matter will run out of the activated carbon and enter the catalytic chamber for catalytic decomposition into C02 and H20, and release energy at the same time. When the released energy enters the adsorption bed for desorption, the heating device stops working, and the organic waste gas maintains spontaneous combustion in the catalytic combustion chamber, and the tail gas circulates until the organic matter is separated from the activated carbon and decomposed in the catalytic chamber.
越華潤華告訴大家voc催化燃燒設備是如何進行環保創獻的？大家在購買的過程中一定要根據自我的需求來考量！
Yuehua Runhua tells you how VOC catalytic combustion equipment makes environmental contribution? Everyone in the purchase process must be based on their own needs to consider!
